When designing Astra, the objective was simple. Develop a high performance luminaire in a smaller form factor. Astra demonstrates beautiful aesthetics and engineering while providing superb and accurate colour rendering, all without sacrificing light output.
When designing Astra, our objective was simple. Develop a high performance luminaire in a smaller form factor than its larger Eve sibling. Astra demonstrates beautiful aesthetics and engineering while providing superb and accurate colour rendering, all without sacrificing light output. Finally, we added our trade tested spring clip V2 to the design for strong, stable and reliable product installation.
Astra outputs a similar light output to it's much larger sibling Eve G4. Our engineering team developed a highly advanced housing structure that not only looks beautiful but is safe, operates at low temperatures and is highly efficient.
The design principal for Astra was based on the long standing and highly respected Eve LED series of recessed luminaries. Astra carries its heritage with impeccable mechanical and visual design. Astra LED is bright, easy to install, and low profile without sacrificing performance. Astra fits a variety of ceilings with three trim colour options and three light colour options.
With years of experience in lighting engine design we have selectively chosen the optimal LED technology for Astra LED. We developed a custom designed circuit board and optics to ensure maximum light delivery in an ultra reliable platform. Boasting over 950 lumens of light at under 11.5W1 is an incredible feat in itself. Astra also features 90+ CRI colour rendering all models. You'll experience smooth, wide beam light that has superb colour rendering and exceptional lifespan with an L70 lifespan exceeding 60,000 hours2.
Astra has 3 trim colour options to choose from. Black, brushed aluminium and Visionary white. Our black is matte black and is anti-reflective to reduce glare. Our brushed trim has the aluminium directly brushed rather than applying heavy metals to the trim. Our white trim is powder coated using a special formulation that is extremely durable and designed for the most popular ceiling paints used in New Zealand.
Compatible with over 90% of New Zealand wall dimmer systems and most smart home electronics3.
Suitable as an update for all 105mm downlights with cutouts between 87-100mm and trims up to 106mm.
Full 10 Year warranty4 on both the lamp and the included LED driver for peace of mind. *7-year commercial.
The attached Phoenix 3 LED driver is fully insulation coverable with approved insulation types.
Fully IC-F rated for use under all NZ approved insulation types including Pink Batts and Earthwool.
Available with superior colour rendering typically measured to be 90+ CRI for premium quality light colour rendering.
Designed with a fully sealed front lens to ensure no air movement from room-space to ceiling cavity.
Suitable for use in bathrooms + kitchens and indoor humid environments as well as under soffits.
SCB & HCB = Zero meaning that the product can abut combustible building elements safely.
A custom formulated trim finish to be highly durable. The trim colours are designed to match common design elements.
Premium quality components and thermal design help ensure a long product lifespan2.
Includes Visionary's proprietary CCT binning technology 'Tru-light' to ensure consistent colour.
Fixed LED Recessed Luminaire
Fixed LED Recessed Luminaire
Product specifications are subject to change without notice.
Footnotes
Visionary Technologies reserves the right to make changes to this document and the product described herein, at anytime, without obligation on Visionary to provide notification of such change. All functionality, features, specifications and other product information provided in this document including, but not limited to, the benefits, design, pricing, components, performance, availability, and capabilities of the product are subject to change without notice or obligation.
1. Reported total lumen flux recorded using Astra model (E90-DW4K) Total lumen flux varies based on product sub model, reflector and lens choices and technology use.
2. LM80 data (TM-21 10K) 10,000 hours of testing. 60,500 hours is based on L70 calculated data as per LM80 testing parameters.
3. 10 year warranty applies to the lamp and approved attached Phoenix Series LED driver. 7 year warranty on lamp and driver applies when being used in a commercial building. Please read our warranty disclosure statement on our website (found under the support menu) for more information.
4. Tested using 17 of the most common dimmers in New Zealand using Visionary lamp model E12W-Dx3K on a 1-2 lamp load.
5. 97+ CRI model applies to when Iris 2 is used with Studio Technology. 90+ CRI when used with its Base model.
